Creating a Single Node M3 Cluster with Docker

This guide shows how to install and configure M3, create a single-node cluster, and read and write metrics to it.

Deploying a single-node cluster is a great way to experiment with M3 and get an idea of what it has to offer, but isn’t designed for production use. To run M3 in clustered mode with a separate M3 Coordinator, read the clustered mode guides.

Prerequisites

  • Docker: You don’t need Docker to run M3DB, but it’s the simplest and quickest way.
    • If you use Docker Desktop, we recommend the following minimum Resources settings.
      • CPUs: 2
      • Memory: 8GB
      • Swap: 1GB
      • Disk image size: 16GB
  • JQ: This example uses jq to format the output of API calls. It isn’t essential for using M3DB.
  • curl: This example uses curl for communicating with M3DB endpoints. You can also use alternatives such as Wget and HTTPie.

Start Docker Container

By default the official M3 Docker image configures a single instance as one binary containing:

  • An M3DB storage instance for time series storage. It includes an embedded tag-based metrics index and an etcd server for storing the cluster topology and runtime configuration.
  • A M3 Coordinator instance for writing and querying tagged metrics, as well as managing cluster topology and runtime configuration.

The Docker container exposes two ports:

  • 7201 to manage the cluster topology, you make most API calls to this endpoint
  • 7203 for Prometheus to scrape the metrics produced by M3DB and M3 Coordinator

The command below creates a persistent data directory on the host operating system to maintain durability and persistence between container restarts.

docker run -p 7201:7201 -p 7203:7203 --name m3db -v $(pwd)/m3db_data:/var/lib/m3db quay.io/m3db/m3dbnode:v1.1.0

Docker pull and run

When running the command above on Docker for Mac, Docker for Windows, and some Linux distributions you may see errors about settings not being at recommended values. Unless you intend to run M3 in production on macOS or Windows, you can ignore these warnings.

Configuration

The single-node cluster Docker image uses this sample configuration file by default.

The file groups configuration into coordinator or db sections that represent the M3Coordinator and M3DB instances of single-node cluster.

You can find more information on configuring M3 in the operational guides section.

Organizing Data with Placements and Namespaces

A time series database (TSDB) typically consist of one node (or instance) to store metrics data. This setup is simple to use but has issues with scalability over time as the quantity of metrics data written and read increases.

As a distributed TSDB, M3 helps solve this problem by spreading metrics data, and demand for that data, across multiple nodes in a cluster. M3 does this by splitting data into segments that match certain criteria (such as above a certain value) across nodes into shards.

If you’ve worked with a distributed database before, then these concepts are probably familiar to you, but M3 uses different terminology to represent some concepts.

  • Every cluster has one placement that maps shards to nodes in the cluster.
  • A cluster can have 0 or more namespaces that are similar conceptually to tables in other databases, and each node serves every namespace for the shards it owns.

For example, if the cluster placement states that node A owns shards 1, 2, and 3, then node A owns shards 1, 2, 3 for all configured namespaces in the cluster. Each namespace has its own configuration options, including a name and retention time for the data.

Create a Placement and Namespace

This quickstart uses the http://localhost:7201/api/v1/database/create endpoint that creates a namespace, and the placement if it doesn’t already exist based on the type argument.

You can create placements and namespaces separately if you need more control over their settings.

In another terminal, use the following command.

#!/bin/bash
curl -X POST http://localhost:7201/api/v1/database/create -d '{
  "type": "local",
  "namespaceName": "default",
  "retentionTime": "12h"
}' | jq .


{
  "namespace": {
    "registry": {
      "namespaces": {
        "default": {
          "bootstrapEnabled": true,
          "flushEnabled": true,
          "writesToCommitLog": true,
          "cleanupEnabled": true,
          "repairEnabled": false,
          "retentionOptions": {
            "retentionPeriodNanos": "43200000000000",
            "blockSizeNanos": "1800000000000",
            "bufferFutureNanos": "120000000000",
            "bufferPastNanos": "600000000000",
            "blockDataExpiry": true,
            "blockDataExpiryAfterNotAccessPeriodNanos": "300000000000",
            "futureRetentionPeriodNanos": "0"
          },
          "snapshotEnabled": true,
          "indexOptions": {
            "enabled": true,
            "blockSizeNanos": "1800000000000"
          },
          "schemaOptions": null,
          "coldWritesEnabled": false,
          "runtimeOptions": null
        }
      }
    }
  },
  "placement": {
    "placement": {
      "instances": {
        "m3db_local": {
          "id": "m3db_local",
          "isolationGroup": "local",
          "zone": "embedded",
          "weight": 1,
          "endpoint": "127.0.0.1:9000",
          "shards": [
            {
              "id": 0,
              "state": "INITIALIZING",
              "sourceId": "",
              "cutoverNanos": "0",
              "cutoffNanos": "0"
            },
            …
            {
              "id": 63,
              "state": "INITIALIZING",
              "sourceId": "",
              "cutoverNanos": "0",
              "cutoffNanos": "0"
            }
          ],
          "shardSetId": 0,
          "hostname": "localhost",
          "port": 9000,
          "metadata": {
            "debugPort": 0
          }
        }
      },
      "replicaFactor": 1,
      "numShards": 64,
      "isSharded": true,
      "cutoverTime": "0",
      "isMirrored": false,
      "maxShardSetId": 0
    },
    "version": 0
  }
}

Placement initialization can take a minute or two. Once all the shards have the AVAILABLE state, the node has finished bootstrapping, and you should see the following messages in the node console output.

{"level":"info","ts":1598367624.0117292,"msg":"bootstrap marking all shards as bootstrapped","namespace":"default","namespace":"default","numShards":64}
{"level":"info","ts":1598367624.0301404,"msg":"bootstrap index with bootstrapped index segments","namespace":"default","numIndexBlocks":0}
{"level":"info","ts":1598367624.0301914,"msg":"bootstrap success","numShards":64,"bootstrapDuration":0.049208827}
{"level":"info","ts":1598367624.03023,"msg":"bootstrapped"}

You can check on the status by calling the http://localhost:7201/api/v1/services/m3db/placement endpoint:

curl http://localhost:7201/api/v1/services/m3db/placement | jq .


{
  "placement": {
    "instances": {
      "m3db_local": {
        "id": "m3db_local",
        "isolationGroup": "local",
        "zone": "embedded",
        "weight": 1,
        "endpoint": "127.0.0.1:9000",
        "shards": [
          {
            "id": 0,
            "state": "AVAILABLE",
            "sourceId": "",
            "cutoverNanos": "0",
            "cutoffNanos": "0"
          },
          …
          {
            "id": 63,
            "state": "AVAILABLE",
            "sourceId": "",
            "cutoverNanos": "0",
            "cutoffNanos": "0"
          }
        ],
        "shardSetId": 0,
        "hostname": "localhost",
        "port": 9000,
        "metadata": {
          "debugPort": 0
        }
      }
    },
    "replicaFactor": 1,
    "numShards": 64,
    "isSharded": true,
    "cutoverTime": "0",
    "isMirrored": false,
    "maxShardSetId": 0
  },
  "version": 2
}

Read more about the bootstrapping process.

Ready a Namespace

Once a namespace has finished bootstrapping, you must mark it as ready before receiving traffic by using the http://localhost:7201/api/v1/services/m3db/namespace/ready.

#!/bin/bash
curl -X POST http://localhost:7201/api/v1/services/m3db/namespace/ready -d '{
  "name": "default"
}' | jq .

{
"ready": true
}

View Details of a Namespace

You can also view the attributes of all namespaces by calling the http://localhost:7201/api/v1/services/m3db/namespace endpoint

curl http://localhost:7201/api/v1/services/m3db/namespace | jq .

Add ?debug=1 to the request to convert nano units in the output into standard units.

{
  "registry": {
    "namespaces": {
      "default": {
        "bootstrapEnabled": true,
        "flushEnabled": true,
        "writesToCommitLog": true,
        "cleanupEnabled": true,
        "repairEnabled": false,
        "retentionOptions": {
          "retentionPeriodNanos": "43200000000000",
          "blockSizeNanos": "1800000000000",
          "bufferFutureNanos": "120000000000",
          "bufferPastNanos": "600000000000",
          "blockDataExpiry": true,
          "blockDataExpiryAfterNotAccessPeriodNanos": "300000000000",
          "futureRetentionPeriodNanos": "0"
        },
        "snapshotEnabled": true,
        "indexOptions": {
          "enabled": true,
          "blockSizeNanos": "1800000000000"
        },
        "schemaOptions": null,
        "coldWritesEnabled": false,
        "runtimeOptions": null
      }
    }
  }
}

Writing and Querying Metrics

Writing Metrics

M3 supports ingesting statsd and Prometheus formatted metrics.

This quickstart focuses on Prometheus metrics which consist of a value, a timestamp, and tags to bring context and meaning to the metric.

You can write metrics using one of two endpoints:
